The Garmin B75M is a broadband bronze thru-hull transducer built with a tilted internal element that self-adjusts to varying hull deadrises — no fairing block needed. It reads depth and water temperature simultaneously, and when paired with a compatible sonar module such as the GSD 26, it supports both Traditional and Spread Spectrum scanning modes. Data travels over the Garmin Marine Network through an 8-pin connector, making it a straightforward upgrade for boats with hulls in the 0–7° deadrise range.

Specifications:

• Housing Material: Bronze thru-hull
• Mount Style: Flush-mount, 0° tilt
• Power Output: 600W
• Max Depth: 800 ft
• Supported Deadrise/Transom Angles: 0–7°
• Data Output: Depth and temperature
• Connector: 8-pin
• Network Compatibility: Garmin Marine Network
• Scanning Modes: Traditional and Spread Spectrum (compatible sonar required)

Resources:

• Owner's Manual (PDF)
• Product Brochure (PDF)
