The Airmar DST810 is a plastic hull-mount multisensor combining depth, speed-through-water, water temperature, and boat attitude data into a single NMEA 2000 transducer. A second-generation paddlewheel delivers 5 Hz speed output for noticeably smoother readings, while the integrated attitude sensor enables heel-compensated speed calibration across multiple heel angles and speed ranges. Built-in Bluetooth Low Energy connects wirelessly to Airmar's free CAST App, letting you perform basic and advanced speed calibrations, configure PGNs, and set output rates independent of any onboard display system. All calibration data and NMEA configurations are stored directly in the DST810 sensor itself.

Specifications:

• Depth Frequency: 235 kHz
• Minimum Depth Range: 0.5 m (1.6 ft)
• Maximum Depth Range: Up to 100 m (330 ft) via NMEA 2000
• Speed Range: Up to 45 knots
• Speed Output Rate: 5 Hz (5 times per second)
• Hull Deadrise: Up to 22°
• Integrated attitude sensor for heel and trim — supports off-center mounting correction
• Wireless Protocol: Bluetooth Low Energy (BLE)
• Wireless Range: Up to 30 ft depending on mount location
• Network Protocol: NMEA 2000
• Standard Cable Length: 6 m (20 ft) DeviceNet — NMEA 2000
• Temperature Sensor Accuracy: ±0.5°C (±1.8°F)
• Temperature Sensor Range: -10°C to 40°C (14°F to 104°F)
• Supply Voltage: 9 VDC to 16 VDC per NMEA 2000 specification
• Housing Material: Plastic

CAST App Capabilities (iOS & Android via Bluetooth):

• Calibrate speed-through-water independent of onboard instrument brand or model
• Perform basic and advanced heel-compensated speed calibrations across the full speed range
• Enter manual speed values for multiple heel angles and up to 10 speed points — previously required expensive PC-based software
• Enable and disable PGNs; set data offsets and output rates
• All configurations stored in the DST810 sensor, not in the display

This product may not be returned to the original point of purchase. Please contact Airmar directly with any product issues or concerns.
