The Garmin Transom Mount Depth/Temp transducer is a dual-frequency plastic transom-mount unit designed as a replacement or upgrade for compatible Garmin fishfinders. Operating at both 50 and 200 kHz with an 8-pin connector, it reads bottom down to 1,500 ft and handles a wide range of transom angles straight out of the box. Users pairing this transducer with a 6-pin Garmin sounder will need adapter cable part number 010-11612-00, sold separately.

Specifications:

• Connector: 8-pin
• Power: 500 W
• Operating frequency: 50/200 kHz (dual frequency)
• Maximum depth: 1,500 ft
• Beamwidth: 40 degrees (50 kHz) / 10 degrees (200 kHz)
• Transom mount angle range: 0 to 70 degrees
• Mount type: Plastic transom mount
• Includes temperature sensing
• Comes with installation instructions
• Compatible adapter for 6-pin Garmin sounders: part number 010-11612-00 (sold separately)

Resources:

• Owner's Manual (PDF)
