The Furuno B60-12 is a bronze through-hull transducer engineered for hulls with 8°–15° deadrise angles. Its internally tilted ceramic element eliminates the need for a fairing block while delivering a true vertical beam for accurate depth returns. The low-profile housing extends only 5 mm (3/16") below the hull, keeping drag to a minimum.

Specifications:

• Model: B60-12, 12° Tilted Element
• Compatible Deadrise Range: 8°–15°
• Housing Material: Bronze
• Frequencies: 50/200 kHz
• Power: 600W RMS
• Performance Class: Mid-performance
• Functions: Depth / Temperature
• Hull Extension: 5 mm (3/16") below hull
• Connector: 10-Pin
• Fairing Block Required: No

Resources:

• Owner's Manual (PDF)
• Product Brochure (PDF)
