The Furuno 200WX Ultrasonic Weather Station is a solid-state, all-in-one sensor built to deliver continuous, accurate weather data even in harsh marine conditions. It measures apparent and true wind speed and direction, air temperature, and wind chill, while an integrated 3-Axis solid-state compass and 3-Axis Rate Gyro provide best-in-class compass performance along with precise pitch and roll data. Compatible with both NMEA 2000 and NMEA 0183 networks, the 200WX connects directly to NavNet TZtouch, TZtouch2, and TZtouch3 systems and draws power from the NMEA 2000 bus — eliminating the need to run dedicated power cables back to the main processor. Its UV-stabilized, fully waterproof housing resists chemicals and sunlight, and the standard 1-inch mount fits existing hardware for straightforward installation.

Specifications:

• Measures apparent and true wind speed and direction
• Measures air temperature and wind chill temperature
• Integrated 3-Axis solid-state compass
• Integrated 3-Axis Rate Gyro for pitch and roll accuracy
• Supports CAN BUS / NMEA 2000® and NMEA 0183 protocols
• Built-in NMEA 2000® port for direct network integration
• Compatible with NavNet TZtouch, TZtouch2, and TZtouch3
• Powered directly from the NMEA 2000® bus
• NMEA 2000® data converted and distributed throughout the network
• Standard 1-inch mount — fits existing mounted hardware
• UV-stabilized, compact housing; fully waterproof
• Chemical and sunlight resistant
• Includes 6 m drop cable (NMEA 2000)

Resources:

• Owner's Manual (PDF)
• Product Brochure (PDF)
