The Newmar 12-24-7 is a standard, non-isolated step-up DC-DC converter designed to produce 24 volts from a 12-volt system — a practical solution for powering the Furuno DRS12AX X-Class Open Array and other dual-voltage marine electronics without adding a dedicated 24V battery bank or charging system. The shared negative ground design suits negative ground vessel installations, and continuous-duty capability means it can run around the clock without cycling down.

Standard, Non-Isolated Series Features:

• Intended for use on negative ground systems
• 10–15 VDC input range
• 7 amp continuous output
• Current limiting, voltage spike suppression, automatic thermal shutdown, and automatic recovery

Specifications:

• Input: 10–15V DC
• Output: 27.2 VDC +/- 5% at extreme temperature, load, input, and tolerance conditions
• Ripple: <100mV P-P
• Regulation: +/- 5% Line/Load
• Duty Cycle — Intermittent: 2 minutes at 20% duty
• Duty Cycle — Continuous: 24 hours at 100% duty
• Operating Temperature: -25° to 30°C; derate linearly from 30° to 0% at 80°C
• Efficiency: 93% typical
• Enclosure: Anodized aluminum with glass-filled polycarbonate; rated IP533 for dust, water, and impact resistance
• Connections: Front panel terminal block
• Output Indicator: Green LED
