The Airmar CM599LH is a CHIRP-ready, dual-band pocket-mounted transducer built for serious deep-water fishing. A 24-element low-frequency array covers 28–60 kHz for penetration to 3,048 m (10,000'), while a single high-frequency ceramic operates across 130–210 kHz with a tight 8°–4° beamwidth for superior target resolution. With 2–3 kW of power, 112 kHz of total bandwidth from one unit, and a urethane resin housing designed for wet-box installation in cavities or welded tanks, the CM599LH delivers professional-grade sonar performance on fiberglass or metal hulls of 8 m (25') and above. Bare-wire termination allows direct integration with compatible chartplotters and fish finders. Patented Xducer ID® technology and built-in depth and fast-response water-temperature sensing round out this offshore-capable transducer.

Specifications:

• Frequency Band: Low-High (Dual-Band, CHIRP-Ready)
• Low Frequency: 28–60 kHz
• High Frequency: 130–210 kHz
• Total Bandwidth: 112 kHz
• Low Frequency Beamwidth: 11°×23° – 5°×9° (fore-aft × port-starboard)
• High Frequency Beamwidth: 8°–4°
• Power Rating: 2–3 kW
• Max Depth (Low Frequency): 3,048 m (10,000')
• Max Depth (High Frequency): 457 m (1,500')
• Functions: Depth, Temperature
• Material: Urethane
• Mounting Style: Tank, Cavity, Pocket/Keel Mount
• Connector: Bare Wire
• Hull Material: Fiberglass or Metal
• Max Vessel LOA: 8 m (25') and above
• Max Deadrise Angle: Accommodates any deadrise angle based on custom installation
• Tilted Element: No
• Common Use: Fishing, Commercial Fishing
• Cable Length: 15 m (49')
• Weight: 14.2 kg (31.2 lb.)
• Country of Origin: USA
• Also available as thru-hull external (R509LH) and in-hull (R599LH) mounts
• Features Patented Xducer ID® Technology
